PRODUCT FEATURES
1.On-wall type operator, easy installation and good-looking appearance.
2.Control system is designed in accordance with the safety requirements of medical electrical system and its multiform control modes could be adopted according to the hospital’s requirements.
3.When the safety sensor detects the obstacles while the door is closing, the door will rebound automatically to ensure the safety of passengers and equipment.
4.Running quietly and smoothly, with excellent sound insulation performance.
SPECIFICATIONS
| Max weight: | single 150kg, double 130kg*2 |
| Open speed: | 250~550mm/s (Adjustable) |
| Close speed: | 250~550mm/s (Adjustable) |
| Hold open delay: | 2~20s (Adjustable) |
| Closing force: | >70N |
| Manual open force: | <100N |
| Voltage: | 220V±10%, 50~60Hz |
| Power consumption: | <150W |
| Working temperature: | -20~+50℃ |
